POWER ADAPTERS

Non-locking barrel plug, 12 VDC, 1.5 A, 100 to 240 VAC, AU plug, 0 to 40°C operating temperature
power-adapters
100 to 240 VAC power input
-40 to 75°C operating temperature range (-T models)

Input Power Parameters

  • Voltage Range: 100 to 240 VAC (50 to 60 Hz)

Power Parameters

  • Input Plug Type: AU
  • Output Power Rating: 1.5 A @ 12 VDC
  • Output Plug Type: Connector Type: L-Type 5.5/2.1/9.0

Physical Characteristics

  • Dimensions: 70 x 55 x 56 mm (2.76 x 2.17 x 2.21 in)
  • Weight: 200 g (0.44 lb)
  • Cord Length: 1800±200 mm (70.87±7.87 in)

Environmental Limits

  • Operating Temperature: 0 to 40°C (32 to 104°F)
  • Storage Temperature: -20 to 70°C (-4 to 158°F)

Standards and Certifications

  • Safety: RCM

Warranty

  • Details: See www.moxa.com/warranty
  • Warranty Period: 1.5 years
