Antenna Characteristics

• Frequency: 800/900/1800/2100/2600 MHz
• Antenna Type: Omni-directional
• Typical Antenna Gain: 2 dBi
• Connector: SMA (male)
• Impedance: 50 ohms
• Polarization: Linear, Vertical
• HPBW/Horizontal: 360°
• V.S.W.R.: 3

Physical Characteristics

• Weight: 26 g (0.06 lb)
• Length: 161 mm (6.34 in)
• Radome Color: Black
• Radome Material: Plastic
• Installation: Straight mount

Environmental Limits

• Operating Temperature: -20 to 65°C (-4 to 149°F)
• Storage Temperature (package included): -20 to 65°C (-4 to 149°F)
• Ambient Relative Humidity: 5 to 95% (30°C, non-condensing)

Warranty

• Warranty Period: 1 year
• Details: See www.moxa.com/warranty
