Antenna Characteristics

• Frequency: 2.4 to 2.5 GHz
• Antenna Type: Omni-directional, Rubber antenna
• Typical Antenna Gain: 5 dBi
• Connector: RP-SMA (male)
• Impedance: 50 ohms
• Polarization: Linear
• HPBW/Horizontal: 360°
• HPBW/Vertical: 80°
• V.S.W.R.: 2:1 max.

Physical Characteristics

• Weight: 300 g (0.66 lb)
• Length (including base): 236 mm (9.29 in)
• Radome Color: Black
• Radome Material: Plastic
• Installation: Magnetic mount
• Cable: RG-174
• Cable Length: 1.5 m

Environmental Limits

• Operating Temperature: -40 to 80°C (-40 to 176°F)
• Storage Temperature (package included): -40 to 80°C (-40 to 176°F)
• Ambient Relative Humidity: 5 to 95% (30°C, non-condensing)

Warranty

• Warranty Period: 1 year
• Details: See www.moxa.com/warranty
