Input/Output Interface

• Digital Input Channels: 16
• Isolation: 3k VDC or 2k Vrms

Digital Inputs

• Voltage: 24 to 110 VDC
• Connector: Spring-type Euroblock terminal
• Debouncing Function: Software enable/disable
• Debouncing Time: 1 to 15 ms (software-selectable)
• I/O Mode: DI
• Points per COM: 8 channels
• Scan on Time: 0.5 ms
• Scan Period: 8 ms (typical)
• Sensor Type: PNP
• Wet Contact (DI to COM): On: > 0.3 times external power voltage Off: 0.15 times external power voltage

Power Parameters

• Power Consumption: 12.6 mA @ 24 VDC

Physical Characteristics

• Dimensions: 25 x 128.2 x 85.5 mm (0.98 x 5.05 x 3.37 in)
• Weight: Under 80 g
• Wiring: I/O cable, 16 to 28 AWG

Environmental Limits

• Operating Temperature: -40 to 75°C (-40 to 167°F)
• Storage Temperature (package included): -40 to 85°C (-40 to 185°F)
• Ambient Relative Humidity: 5 to 95% (non-condensing)
• Altitude: 2000 m
• Altitude: Please contact Moxa if you require products guaranteed to function properly at higher altitudes.

Standards and Certifications

• EMC: EN 55032/24, EN 61000-6-2/-6-4
• EMI: CISPR 32, FCC Part 15B Class A
• EMS: IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV IEC 61000-4-3 RS: 5100 MHz to 6000 MHz: 3 V/m IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV IEC 61000-4-6 CS: 10 V IEC 61000-4-8 PFMF
• Railway: EN 50121-4, EN 50155
• Safety: UL 508
• Shock: IEC 60068-2-27
• Vibration: IEC 60068-2-6

MTBF

• Time: 1,115,244 hrs
• Standards: Telcordia SR332

Warranty

• Warranty Period: 5 years
• Details: See www.moxa.com/warranty

Digital Outputs

• Connector: Spring-type Euroblock terminal
• I/O Mode: DO or PWM
