ONCELL G4308-LTE4 SERIES

Industrial LTE Cat. 4 cellular secure router, global band support, 8 10/100/1000BaseT(X) RJ45 ports, -10 to 55°C operating temperature
oncell-g4308-lte4-series

Cellular Interface

  • Cellular Standards: LTE CAT 4, HSPA, UMTS
  • Data Rate: 20 MHz bandwidth: 150 Mbps DL, 50 Mbps UL
  • Frequency Bands Supported: LTE B1 (2100 MHz) / B2 (1900 MHz) / B3 (1800 MHz) / B4 (1700/2100 MHz (AWS)) / B5 (850 MHz) / B7 (2600 MHz) / B8 (900 MHz) / B12 (700 MHz) / B13 (700 MHz) / B14 (700 MHz) / B20 (800 MHz) / B25 (1900 MHz) / B26 (850 MHz) / B28 (700 MHz)UMTS/HSPA B1 (2100 MHz) / B2 (1900 MHz) / B4 (1700 MHz(AWS)) / B5 (850 MHz) / B6 (800MHz) / B8 (900 MHz) / B19 (800 MHz)
  • No. of SIMs: 2 Push-eject tray type
  • SIM Format: Nano SIM
  • Cellular Antenna Connectors: 2 x SMA female

Ethernet Interface

  • 10/100/1000BaseT(X) Ports (RJ45 connector): 8
  • Standards: IEEE 802.3 for 10BaseT IEEE 802.3u for 100BaseT(X) IEEE 802.3ab for 1000BaseT(X)

GNSS Interface

  • GNSS Bands: GPS (1575.42 MHz)GLONASS (1597.52 MHz)Galileo (1575.42 MHz)BeiDou (1561.098 MHz)
  • GNSS Antenna Connectors: 1 x SMA female

Input/Output Interface

  • Digital Output Channels: 1 Relay output with current carrying capacity of 1 A @ 24 VDC
  • Digital Input Channels: 1
  • Digital Inputs: 0 to +3 V for state 0 +9 to +36 V for state 1
  • Buttons: Reset button

USB Interface

  • No. of USB Ports: 1
  • USB Connector: USB Type A
  • USB Standards: USB 2.0
  • USB Standards: For use with the ABC-02 Series configuration backup and restoration tool.

Serial Interface

  • No. of Ports: 1
  • Connector: DB9 male
  • Serial Standards: RS-232/422/485
  • Data Bits: 5, 6, 7, 8
  • Stop Bits: 1, 1.5, 2
  • Parity: None Even Odd
  • Baudrate: 300 bps to 921.6 kbps
  • Console Port: RS-232 (TxD, RxD, GND), USB type-C (115200, n, 8, 1)
  • Console Port: We recommend using the Moxa CBL-USBCF9-GY-150 console cable, which can be purchased separately.

Serial Signals

  • RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
  • RS-422: Tx+, Tx-, Rx+, Rx-, GND
  • RS-485-2w: Data+, Data-, GND
  • RS-485-4w: Tx+, Tx-, Rx+, Rx-, GND

Operation Modes

  • Standards: Real COM mode RFC2217 mode TCP Client mode TCP Server mode UDP mode SCATS

LED Interface

  • LED Indicators: PWR1, PWR2, STATE, USB, SIM1, SIM2, CELL, LTE, GNSS, SERIAL, VPN

Wireless Software Features

  • Management: GuaranLink Send SMS SMS Remote Control Moxa Remote Connect (MRC)

Ethernet Software Features

  • Management: DHCP Server/Client DNS Syslog MXview One MXconfig MXsecurity Power Management
  • Broadcast Forwarding: IP directed broadcast, broadcast forwarding
  • Configuration Options: We recommend using the Moxa CBL-USBCF9-GY-150 console cable, which can be purchased separately.
  • Configuration Options: We recommend using the Moxa CBL-USBCF9-GY-150 console cable, which can be purchased separately.
  • Configuration Options: Web Console (HTTP/HTTPS) Command Line Interface (CLI) through Serial/Telnet/SSH
  • Network Protocols: LLDP SMTP SNMPv1/v2c/v3 TFTP TCP/IP UDP IPv4 ARP HTTP/HTTPS Telnet SSH
  • Filter: 802.1Q VLAN Port-based VLAN
  • Unicast Routing: OSPF RIPV1/V2 Static Route
  • Multicast Routing: Static Route
  • Routing Redundancy: VRRP
  • Time Management: NTP Server/Client SNTP
  • Tunneling: GRE
  • VPN: IPsec OpenVPN

Security Functions

  • Hardware-based Security: Secure Boot
  • Password: User-level password protection
  • Authentication: Local database RADIUS Access Control List

DoS and DDoS Protection

  • Technology: ARP-Flood FIN Scan ICMP Flood TCP Sessions Without SYN NMAP-ID Scan NMAP-Xmas Scan Null Scan SYN/FIN Scan SYN/RST Scan SYN-Flood Xmas Scan

Firewall

  • Filter: DDoS Ethernet protocols ICMP IP address MAC address Ports
  • Deep Packet Inspection: Modbus TCP Modbus UDP DNP3 IEC 60870-5-104 IEC 61850 MMS EtherNet/IP MELSEC Omron FINS OPC UA Siemens S7 Comm. Siemens S7 Comm. Plus Additional protocols will be supported through future firmware updates.

NAT

  • Features: 1-to-1 N-to-1 PAT NAT loopback Double NAT

IPsec VPN

  • Authentication: MD5 and SHA (SHA-256) RSA (key size: 1024-bit, 2048-bit) Pre-shared Key or X.509 v3 certificate
  • Encryption: DES 3DES AES-128 AES-192 AES-256 AES-256 GCM
  • Concurrent VPN Tunnels: Max. 15 IPsec VPN tunnels

OpenVPN

  • OpenVPN: OpenVPN (client)
  • Encryption: AES-128/192/256 CBC AES-128/192/256 GCM CHACHA20-POLY1305

Power Parameters

  • Input Current: 1.16 A (max.)
  • Input Voltage: 12 to 48 VDC Redundant dual inputs
  • Power Consumption: 47 mW at 12 V (idle)11.05 W at 12 V (typ.)14.28 W at 48 V (max.)
  • Power Connector: Screw-locked terminal block
  • Reverse Polarity Protection: Supported

Physical Characteristics

  • Housing: Metal
  • Dimensions: 125 x 58.2 x 100 mm (4.92 x 2.29 x 3.94 in)
  • Weight: 707 g (1.56 lb)
  • Installation: DIN-rail mounting Wall mounting (with optional kit)
  • IP Rating: IP40
  • IP Rating: With the rubber SIM slot cover closed.

Environmental Limits

  • Operating Temperature: -10 to 55°C (14 to 131°F)
  • Storage Temperature (package included): -40 to 85°C (-40 to 185°F)
  • Ambient Relative Humidity: 5 to 95% (non-condensing)

Standards and Certifications

  • EMC: EN 55032/35 EN 61000-6-2/-6-4 CISPR 32/35
  • EMI: ICES-003, FCC Part 15B Class A
  • EMS: This device demonstrates a capacity that exceeds the requirements set by certification standards.
  • EMS: This device demonstrates a capacity that exceeds the requirements set by certification standards.
  • EMS: IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m (level 3); 1.8, 2.6, 3.5, 5GHz: 3V/m (level 2) IEC 61000-4-4 EFT: Power: 2 kV; IO: 1 kV (level 3)
  • EMS: This device demonstrates a capacity that exceeds the requirements set by certification standards.
  • EMS: IEC 61000-4-5 Surge: Power: Power: 2 kV, Signal: 2 kV (level 3)
  • EMS: This device demonstrates a capacity that exceeds the requirements set by certification standards.
  • EMS: IEC 61000-4-6 CS: 0.15 MHz to 80 MHz; Signal: 10 V (level 3) IEC 61000-4-8: 30 A/m (level 4)
  • Freefall: IEC 60068-2-32
  • Radio Frequency: FCC ID RI7LE910CXWWX PTCRB EN 303 413
  • Radio: RCM UKCA IC: 5131A-LE910CXWWX NCC: CCAK264G0020T7 TELEC: R 003-240163/T D240129003
  • Cellular Standards: EN 301 489-1/-19 (GPS) EN 301 489-1/-52 (WCDMA/LTE) EN 301 511 EN 301908-1/-2/-13
  • Cybersecurity: EN 18031-1
  • Safety: UL 62368-1 EN 62368-1
  • Shock: IEC 60068-2-27
  • Vibration: IEC 60068-2-6

MTBF

  • Time: 1,533,742 hrs
  • Standards: Telcordia Standard SR-332

Warranty

  • Warranty Period: 5 years
  • Details: See www.moxa.com/warranty
